Different Wireshark Interfaces

“
Different Wireshark Interfaces

Wireshark is a network protocol analyzer tool that allows you to capture and analyze network traffic. Its user interface is designed to make it easy to analyze packets and to provide a wealth of information about the traffic that is being captured. The interface consists of several different windows, which are:

1. Capture Options: This window allows you to select the network interface you want to use for capturing traffic, set filters for capturing specific types of traffic, and configure other options related to the capture process.

2. Packet List: This window shows a list of captured packets, and provides a summary of each packet, including the source and destination IP addresses, protocol used, and other details.

3. Packet Details: This window displays the contents of the selected packet, including the various protocol layers that make up the packet, such as Ethernet, IP, TCP, and so on.

4. Packet Bytes: This window shows the raw bytes of the selected packet, which can be useful for debugging or troubleshooting purposes.

5. Protocol Hierarchy: This window shows a hierarchical view of the protocols used in the captured packets, which can help you understand the overall structure of the traffic.

6. Statistics: This window provides statistics on the captured traffic, including the number of packets captured, the amount of data transferred, and other metrics.

7. Filter Expression: This window allows you to enter a filter expression to filter the packets displayed in the packet list.

Overall, the Wireshark interface is designed to make it easy to analyze network traffic and to provide a wealth of information about the traffic that is being captured.
